Ignition, Fuel Controls |
| - |
|
|
Starter (Relay) |
| - |
|
|
Rear Window Defogger, Heated Mirrors (Relay) |
| - |
|
|
Fuel Pump (Relay) |
| - |
|
|
Headlamps (Relay) |
| - |
|
|
Daytime Running Lamps (Relay) |
| - |
|
|
A/C (Relay) |
| - |
|
|
Fog Lamps (Relay) |
| - |
|
|
Horn (Relay) |
| 1 |
|
|
Accessory Power/Trailer. Wiring Feed/Load Leveling |
| 2 |
|
|
Anti-Lock Brakes |
| 3 |
|
|
Ignition Switch |
| 4 |
|
|
AIR. System |
| 5 |
|
|
Retained Accessory Power. Power Mirrors. Power Door Locks. Power Seats |
| 6 |
|
|
Ignition Switch |
| 7 |
|
|
Retained Accessory Power/Rear. Power Windows. Sunroof. Radio. |
| 8 |
|
|
Accessory Power/Trailer Wiring Brake Feed |
| 9 |
|
|
Right Turn Signal Trailer Wiring |
| 10 |
|
|
Left Turn Signal Trailer Wiring |
| 11 |
|
|
Ignition, Fuel Controls (Relay) |
| 12 |
|
|
Parking Lamps |
| 13 |
|
|
Climate Control System |
| 14 |
|
|
Exterior Lamps, Stoplamps |
| 15 |
|
|
VCM/PCM |
| 16 |
|
|
Center High Mounted Stoplamp |
| 17 |
|
|
Stoplamps Cruise Control |
| 18 |
|
|
Backup Lamps Trailer Wiring |
| 19 |
|
|
Fuel Controls. Ignition |
| 20 |
|
|
Rear HVAC |
| 21 |
|
|
Vehicle Backup Lamps |
| 22 |
|
|
Engine Controls. Canister Purge Fuel System |
| 23 |
|
|
Electronic Throttle Control |
| 24 |
|
|
A/C Compressor Relay Rear Window Defogger, Daytime Running Lamps, A.I.R. System |
| 25 |
|
|
Backup Lamps Automatic Transmission Shift Lock Control System |
| 26 |
|
|
Automatic Transfer Case |
| 27 |
|
|
Autoride TM (Real Time Damping) |
| 28 |
|
|
Right Rear Parking Lamps |
| 29 |
|
|
VCM/PCM |
| 30 |
|
|
Oxygen Sensors |
| 31 |
|
|
Oxygen Sensors |
| 32 |
|
|
Left Rear Parking Lamps |
| 33 |
|
|
Rear Window Defogger, Heated Mirrors |
| 34 |
|
|
Parking Lamps Trailer Wiring |
| 36 |
|
|
Right Headlamps |
| 37 |
|
|
Heated Mirrors |
| 38 |
|
|
Left Headlamps |
| 39 |
|
|
Air Conditioning |
| 40 |
|
|
Cigarette Lighter, Auxiliary Power Outlets |
| 41 |
|
|
Special Equipment Option Power Seats, Aux Roof Mnt Lamp |
| 42 |
|
|
Special Equipment Option Aux Roof Mnt Lamp, Cell Phone |
| 43 |
|
|
Daytime Running Lamps |
| 44 |
|
|
Fog Lamps |
| 45 |
|
|
Audio System, Instrument Cluster, Climate Control System |
| 46 |
|
|
Cigarette Lighter, Auxiliary Power Outlets |
| 47 |
|
|
Right Turn Signals |
| 48 |
|
|
Automatic Transmission Shift Lock Control System |
| 49 |
|
|
Left Turn Signals |
| 50 |
|
|
Front Parking Lamps, Sidemarker Lamps |
| 51 |
|
|
Windshield Washer Pump |
| 52 |
|
|
Ignition Switch. Fuel Pump, PRND321 Display, Crank |
| 53 |
|
|
Radio Amplifier |
| 54 |
|
|
Exterior Lamps, Hazard Lamps |
| 56 |
|
|
Horn |
| 57 |
|
|
Interior Lamps |
| 58 |
|
|
Rear Wipers |
| 59 |
|
|
Body Control Module, Remote Keyless Entry Headlamps |
