25A |
(MULTI MEDIA1) [With ISG] Low DC-DC Converter [W/O ISG] Audio, A/V & Navigation Head Unit |
| - |
|
10A |
(MEMORY) Rear A/C Control Module, Low DC-DC Converter, Instrument Cluster, Front A/C Control Panel, Front A/C Control Module, Folding/Unfolding Mirror Relay |
| - |
|
10A |
(E-CALL) Emergency Call (E-call) Module |
| - |
|
7.5A |
(MODULE8) Diesel Filter Heater |
| - |
|
7.5A |
(E-SHIFTER1) Electronic ATM Shift Lever, SCU |
| - |
|
7.5A |
(MODULE5) Dosing Control Module, AWD ECU. Clutch & Ignition Lock Switch, ADAS Unit, Center Facia Switch, Crash Pad Switch, IBU. Lane Departure Warning (LDW) Camera, Rear Radar LH/RH |
| - |
|
10A |
(START1) [With Smart Key] IBU, ECM, Transaxle Range Switch [W/O Smart Key] Ignition Switch, B/Alarm Relay |
| - |
|
15A |
(AIRBAG1) SRS Control Module |
| - |
|
10A |
SPARE |
| - |
|
7.5A |
(AIRBAG IND) Instrument Cluster |
| - |
|
7.5A |
(IBU1) IBU |
| - |
|
20A |
(DOOR LOCK) Relay Box (Center Door Lock/Unlock Relay, Rear LH Door Lock/Unlock Relay) |
| - |
|
10A |
SPARE |
| - |
|
10A |
(MODULE7) Hazard Switch, BSSW Unit |
| - |
|
7.5A |
(MODULE9) IBU |
| - |
|
15A |
(WASHER) Multifunction Switch |
| - |
|
7.5A |
SPARE |
| - |
|
10A |
SPARE |
| - |
|
10A |
(MODULE6) Keyboard, A/V & Navigation Head Unit. Audio, Data Link Connector, Emergency Call (E-call) Module, Front A/C Control Module, AMP, Front A/C Control Panel, Electro Chromic Mirror, Crash Pad Switch, ATM Shift Lever Indicator, Driver Seat Connector, Wireless Charger, Low DC-DC Converter, 2nd Seat LH/RH Relax Unit. Head Lamp LH/RH, 2nd Seat LH/RH Ventilation Seat Control Module |
| - |
|
7.5A |
(A/C) Front A/C Control Panel, Front/Rear A/C Control Module, Sub Junction Block (RLY.6). E/R Junction Block (RLY.3 / RLY.13) |
| - |
|
10A |
(MULTI MEDIA2) Front A/C Control Panel, Front/Rear A/C Control Module, ADAS Unit, Wireless Charger, Instrument Cluster, Rear Radar LH/RH |
| - |
|
7.5A |
(MDPS1) MDPS Unit |
| - |
|
10A |
(START2) Ignition Switch |
| - |
|
10A |
SPARE |
| - |
|
25A |
(SAFETY WINDOWLH) Driver/passenger Safety Power Window Module |
| - |
|
10A |
SPARE |
| - |
|
10A |
(MODULE11) Power Tailgate & Power Sliding Door Switch, Key Solenoid, Data Link Connector, Hazard Switch, ATM Shift Lever, ADAS Unit, Power Tailgate Module, 2nd Seat LH/RH Relax Unit, |
| - |
|
10A |
(AIRBAG2) SRS Control Module |
| - |
|
10A |
SPARE |
| - |
|
10A |
(IBU2) IBU |
| - |
|
10A |
(MODULE3) Emergency Call (E-CALL) Module, IBU. Audio, Keyboard, AMP A/V & Navigation Head Unit |
| - |
|
15A |
(MODULE2) Front USB Charger, Passenger Seat Connector, USB Charger LH/RH, Luggage USB Charger LH/RH, Luggage USB Charger LH/RH (3RD) |
| - |
|
7.5A |
(MODULE10) AC Inverter Module, E/R Junction Block (RLY.4 / RLY.8). AC Inverter Outlet, 2nd Seat LH/RH Relax Unit, 2nd Seat LH/RH Ventilation Seat Control Module |
| - |
|
10A |
SPARE |
| - |
|
10A |
SPARE |
| - |
|
7.5A |
(CLUSTER) Instrument Cluster |
| - |
|
20A |
(SUNROOF1) Front Sunroof Motor |
| - |
|
20A |
(SUNROOF2) Rear Sunroof Motor |
| - |
|
20A |
(P/SEAT REAR LH) 2nd Seat LH Relax Unit |
| - |
|
20A |
(S/HEATER REAR LH) 2nd Seat LH Ventilation Seat Control Module |
| - |
|
20A |
(S/HEATER FRT LH/RH) Driver Seat Connector |
| - |
|
20A |
(P/SEAT REAR RH) 2nd Seat RH Relax Unit |
| - |
|
20A |
(S/HEATER REAR RH) 2nd Seat RH Ventilation Seat Control Module |
| - |
|
10A |
(TAILGATE) Tailgate Release Relay |
| - |
|
10A |
(BRAKE SWITCH) Stop Lamp Switch, IBU |
| - |
|
10A |
(MODULE1) Driver Power Outside Mirror Switch, Low DC-DC Converter, AMP |
| - |
|
15A |
SPARE |
| - |
|
10A |
SPARE |
| - |
|
7.5A |
(MODULE4) Stop Lamp Switch |
| - |
|
25A |
(P/WINDOW RH) Power Window Main Switch, Passenger Power Window Switch |
| - |
|
25A |
(P/WINDOW LH) Power Window Main Switch, Passenger Power Window Switch |
| - |
|
30A |
(P/SEAT FRT RH) Passenger Seat Connector |
| - |
|
30A |
(POWER TAILGATE) Power Tailgate Module |
| - |
|
30A |
(AMP) [With ISG] Low DC-DC Converter [W/O ISG] AMP |
| - |
|
30A |
(P/SEAT FRT LH) Driver Seat Connector |
| - |
|
25A |
(SAFETY WINDOW RH) Driver/Passenger Safety Power Window Module |
